Vacuum bag for laminated glass

Our Vacuum bag for laminated glass is the ideal solution for heat treatment operations of laminated glass. For some processes, you can insert several items simultaneously in the same pocket. Moreover, the pockets can open on one or more sides. This allows an easy insertion and removal of the glass.

Our hot vulcanization manufacturing process gives PRONAL bags all the qualities required in terms of flexibility, softness and resistance.. Moreover, the vacuum bag can be used in an autoclave, horizontally or vertically for any type of glass.

Finally, the PRONAL Vacuum bag for laminated glass is designed to fit any conveyor supporting frame and storage rack.

It is possible to reinforce certain areas in order to protect the vacuum pockets on the corners of windshields for example, or other protruding parts of the glass pieces.

We realize custom-made solutions, do not hesitate to contact our teams for any personalized request (non-standard dimensions).

Avantages

Adaptable

  •  Used in an oven or autoclave
  •  Horizontally or vertically

Resistant

  • To High temperatures in continuous manufacturing cycles
  • Reinforced areas to protect the pockets of the glass corners

Flexibility

  • Prevent glass breakage
  • compatible with all shapes of glass

Vacuum Free Circulation

  • Non-stick internal exhaust chamber: high vacuum rate

Ease and Speed of Use

  • Bag opening on one or several sides thanks to a simple system for easy installation and removal

Productivity

  • Curved or straight glass treatment without special bag settings
  • Several items can be installed in the same bag for certain processes

Informations détaillées

  • Material: elastomer coated fabric with high temperature resistance suitable for oven or autoclave
  • Dimensions: standard (up to 5600 x 2700 mm) and custom made under request > contact us
  • Assembly: Vulcanisation
  • Temperature resistance: up to 150°C
  • Accessories: VACUUM LINE: Several connection diameters
  • Fixation: Snap hook + chains /Straps + press studs, / sheath
  • Opening / Closing : by folding on 1 side – by profile on 1/2/3 sides

Vous ne trouvez pas vos dimensions

Notre bureau d'études composé des meilleurs chefs de projets et de desssinateurs sauront imaginer et créer un produit sur-mesure spécialement pour vous et votre projet unique.

sur mesure
