Raw water storage tank
This raw water storage tank is the standard solution. You can use it for permanent or temporary storage.
Today more than ever, the proper management of water and its preservation represent a considerable economic challenge. They are easy to transport to the site and quick to install. Therefore, PRONAL tanks are the ideal solution to easily build a water reserve.
Indeed, with a quick installation and without the need for a building permit (depending on the size of the tank), the flexible tank allows a saving of nearly 70% compared to rigid solutions. It can also be easily moved.
These flexible tanks can be used:
- For rainwater harvesting: see application
- As a crawl space
- As a water reserve on construction sites
- Or even for sensory experiences: see the project realized by the gardens of Brocéliandes
Like our other tanks, it is made from highly resistant PVC coated fabric (1300 gr/m2) and assembled by high frequency welding. This fabric resists all temperatures from -30°C to +70°C.
In addition, this flexible tank prevents the water from evaporating or being polluted by external elements such as insects or leaves.
The flexible raw water storage tank is 100% customizable.
Advantages
Reliability
- Cost-effective
- Environmentally friendly
- Long service life
Safety
- Constant volume, no evaporation
- No outside pollution: insects, leaves, etc.
- No micro-organism growth
Handling
- No building permit
- Quick and easy deployment
- Can be moved
Detailed information
- Material: high resistance 1300 gr/m2 cloth
- Coating: double-sided PVC
- Dimensions: standard and custom made under request > contact us
- Assembly: high-frequency welding
- Temperature resistance: -30°C to + 70°C
- Accessories:
- 1 DN 140 welded vent to screw-in with gas release valve
- 1 DN 80 elbow overflow with symmetrical connector and cap
- 1 DN 50 PPG quarter-turn guillotine valve assembly + DN 50 symmetrical connector and cap
- 4 reinforced corners
- 1 repair kit
- thermal valve protector
Technical informations
| Ref. | Volume (m3) | Dimensions (mm) | Weight (kg) | Packaging (mm) | Side filling/draining | Overflow |
|---|---|---|---|---|---|---|
| C5EB5 | 5 | 2960x3510x800 | 27 | 1020x620x635 | 2 x Ø2’’ | 1 x Ø2’’ |
| C5EB10 | 10 | 2960x5650x900 | 41 | 1235x820x550 | 2 x Ø2’’ | 1 x Ø2’’ |
| C5EB20 | 20 | 4440x6200x1100 | 65 | 1235x820x750 | 2 x Ø2’’ | 1 x Ø2’’ |
| C5EB50 | 50 | 5920x9530x1300 | 129 | 1235x820x960 | 2 x Ø2’’ | 1 x Ø2’’ |
| C5EB100 | 100 | 8880x10750x1500 | 216 | 1340x940x1080 | 2 x Ø3’’ | 1 x Ø3’’ |
| C5EB250 | 250 | 10360x20410x1500 | 475 | 2170x1260x1380 | 2 x Ø3’’ | 1 x Ø3’’ |
| C5EB500 | 500 | 19240x22060x1500 | 960 | 2200x1700x1000 | 2 x Ø3’’ | 1 x Ø3’’ |
You can not find your dimensions
Our design department employs the best project leaders and designers and will be pleased to develop and create a tailor-made product specially for your unique project.
