Crawl Space Water Storage
This crawl space water storage has the same characteristics as our rainwater storage tank : it collects rainwater through the downspouts.
However, it is placed under the house, in the crawl space, hence its name: crawl space water storage. This saves space; it will not take up space on your property. Moreover, it is hidden and does not disturb the landscape.
This flexible tank has an ecological advantage: we recover rainwater and reuse it for other applications such as watering green spaces, cleaning vehicles for example. This allows us to reduce the consumption of drinking water and thus to preserve the planet a little. Moreover, this reduction in consumption also benefits you economically!
Made from highly resistant coated fabrics, the flexible tank will store water without any problem of leakage or evaporation!
In addition, collecting runoff water is important to avoid the risk of flooding (see our inflatable anti-flooding system).
This tank has a storage capacity limited to the size of the crawl space. If you want a larger storage capacity, we recommend the rainwater storage tank that can be placed next to your house, on your property.
Advantages
Reliability
- Cost-effective
- Environmentally friendly
- Long service life
Safety
- Constant volume, no evaporation
- No outside pollution: insects, leaves, etc.
- No micro-organism growth
Handling
- No building permit
- Quick and easy deployment
- Can be moved
Detailed information
- Material: high resistance 1300 gr/m2 cloth
- Coating: double-sided PVC
- Dimensions: standard and custom made under request > contact us
- Assembly: high-frequency welding
- Temperature resistance: -30°C to + 70°C
- Accessories:
- 1 DN 140 welded vent to screw-in with gas release valve
- 1 DN 80 elbow overflow with symmetrical connector and cap
- 1 DN 50 PPG quarter-turn guillotine valve assembly + DN 50 symmetrical connector and cap
- 4 reinforced corners
- 1 repair kit
- thermal valve protector
Technical informations
| Ref. | Volume (m3) | Dimensions (mm) | Weight (kg) | Packaging (mm) | Side filling/draining | Overflow |
|---|---|---|---|---|---|---|
| C5EB5 | 5 | 2960x3510x800 | 27 | 1020x620x635 | 2 x Ø2’’ | 1 x Ø2’’ |
| C5EB10 | 10 | 2960x5650x900 | 41 | 1235x820x550 | 2 x Ø2’’ | 1 x Ø2’’ |
| C5EB20 | 20 | 4440x6200x1100 | 65 | 1235x820x750 | 2 x Ø2’’ | 1 x Ø2’’ |
| C5EB50 | 50 | 5920x9530x1300 | 129 | 1235x820x960 | 2 x Ø2’’ | 1 x Ø2’’ |
| C5EB100 | 100 | 8880x10750x1500 | 216 | 1340x940x1080 | 2 x Ø3’’ | 1 x Ø3’’ |
| C5EB250 | 250 | 10360x20410x1500 | 475 | 2170x1260x1380 | 2 x Ø3’’ | 1 x Ø3’’ |
| C5EB500 | 500 | 19240x22060x1500 | 960 | 2200x1700x1000 | 2 x Ø3’’ | 1 x Ø3’’ |
You can not find your dimensions
Our design department employs the best project leaders and designers and will be pleased to develop and create a tailor-made product specially for your unique project.
