Drinking Water Bladder
We have designed a specific range of flexible tanks dedicated to the storage of drinking water: The Drinking Water Bladder. This range was created for the water supply of populations or isolated areas.
Made of fabrics and equipment suitable for human consumption, it is, like our other tanks, manufactured from highly resistant PVC coated fabrics and assembled by high frequency welding. Our PVC fabrics comply with the French ACS standard and the European food standard.
In addition, this fabric is resistant to extreme weather conditions and keeps the stored water safe from external contamination.
The Drinking Water Bladder can be deployed for :
- Storage of drinking water on military bases,
- Emergency humanitarian aid and development in water reserves,
- Drinking water storage on construction sites, mining operations..,
- Buffer storage in mobile treatment stations,
- Industrial and food processing.
Indeed, its simple and quick installation allows it to be easily moved and installed in isolated places. Moreover, its installation does not require any civil engineering. It is also very easy to clean.
The drinking water bladder is a standard product. However, we can provide turnkey solutions such as a water purification plant. We have already done it at the Senegal-Mauritania border.
Advantages
Reliability
- Cost effective
- Environmentally friendly
- Long service life
Safety
- Constant volume, no evaporation
- No outside pollution: insects, leaves, etc.
- No micro-organism growth
Handling
- No building permit required
- Quick and easy deployment
- Can be moved
Detailed information
- Material: high resistance 1300gr/m2 cloth
- Coating: double-sided PVC
- Dimensions: standard and custom made under request > contact us
- Assembly: high-frequency welding
- Temperature resistance: -30°C to + 70°C
- Accessories:
- 1 DN 140 welded vent to screw-in with gas release valve
- 1 DN 80 elbow overflow with symmetrical connector and cap
- 1 DN 50 PPG quarter-turn guillotine valve assembly + DN 50 symmetrical connector and cap
- 4 reinforced corners
- 1 repair kit
- thermal valve protector
Technical informations
| Ref. | Volume (m3) | Dimensions (m) | Weight (kg) | Packaging (mm) | Side filling/draining |
|---|---|---|---|---|---|
| CSEP5 | 5 | 3.21x3.24x0.8 | 27 | 1020x620x635 | 2 x Ø2’’ |
| CSEP10 | 10 | 4.28x4.38x0.9 | 45 | 1235x820x550 | 2 x Ø2’’ |
| CSEP20 | 20 | 4.28x6.44x1 | 65 | 1235x820x750 | 2 x Ø2’’ |
| CSEP50 | 50 | 6.42x8.76x1.30 | 129 | 1235x820x960 | 2 x Ø2’’ |
| CSEP100 | 100 | 7.49x12.77x1.50 | 218 | 1340x940x1080 | 2 x Ø3’’ |
| CSEP250 | 250 | 12.84x16.39x1.50 | 475 | 2170x1260x1380 | 2 x Ø3’’ |
| CSEP500 | 500 | 18.19x23.05x1.50 | 950 | 2200x1700x1000 | 2 x Ø3’’ |
You can not find your dimensions
Our design department employs the best project leaders and designers and will be pleased to develop and create a tailor-made product specially for your unique project.
