Bladder surge vessel- MAB
The bladder surge vessel is a compensating membrane. We always install them inside the tanks and grids under pressure. They are able to compensate the variation of the volume and to restrict the effects of water hammers.
Manufactured from elastromeres and plastomeres, this bladder surge vessel forms an interface for the protection of liquids by gases. This product is assembled by high frequency welding or by hot vulcanization in autoclave.
They are designed to :
- absorb water hammer: during a sudden closing or opening of a valve,
- soften pulsations: due to the diaphragm of a pump which generates pressure oscillations
- compensate for a pressure variation: when there is a loss of volume so the pressure can remains the same
Our compensation membranes prevent overpressures that could be harmful to the various elements of the installation.
These flexible membranes are completely watertight. We can customize them to fit the tank in which they will be installed.
For the compensation of more common preservative oils, we find the MTP Rubber Flexible Membrane.
Advantages
Use
- Varied inflation accessories
- Wide ranging chemical compatibility
Safety
- 100% leak-tight
- Ensure tank protection
Handling
- Made to measure
- Every shape is possible
- Quick and easy installation
Detailed information
- Material: polyurethane sheet
- Manufacturing technique: high frequency welding
- Dimensions: made to measure > contact us
- Inflation: air
- Temperature resistance: 0°C to +80°C
- Thickness: 1 mm
- Possible shapes: conical and toroid
- Material options: compatible with oils and hydrocarbons
- Accessories:
- Mild or stainless steel insert
- Mounting insert
- Threaded mounting rod
You can not find your dimensions
Our design department employs the best project leaders and designers and will be pleased to develop and create a tailor-made product specially for your unique project.
